Galvanized 2" x 2" Square Trailer Axle - 3,500 lbs. Capacity with 1 3/8" x 1 1/16" Spindles - 2" Drop - 87.5" Hub Face

More Views

Free Shipping
$220.95

Be the first to review this product

Availability: In stock

Item # 35292A
Approximate Overall Length: 92"
Hub Face: 87 1/2"
Capacity: 3,500 lbs.
Brand: Tie Down Engineering
Manufacturer Product #: 49857

Additional Information

Product Features

Details

The 35292A square axle by Tie Down Engineering/Dexter Marine (manufacturer part number 49857) is a galvanized drop axle with a 3,500 lbs. capacity. The galvanized finish and pressed stainless steel wear rings are designed with marine applications in mind; keeping the beam intact and corrosion resistant. This axle comes pre-drilled by the manufacturer for the springs to sit. The 4 hole flanges on either spindle allow for brake installation.



Product Features:

  • Hot dipped galvanized beam to combat corrosion
  • Galvanized axles will last much longer than painted ones and are perfect for marine applications
  • Features a stainless steel wear sleeve on either spindle
  • Slight camber built into spindle welds
  • Used for leaf spring suspension systems
  • Includes 2 castellated nut, 2 washers, and 2 cotter pins
  • Zerk fitting at end of spindles for simple and easy bearing lubrication
  • Pre-drilled 5/16" drain hole
  • 4-hole flanges for brake mounting
  • Hubs/drums sold separately



Product Specifications:

  • Capacity: 3,500 lbs.
  • Hub Face Measurement: 87.5"
  • Flange to Flange Measurement: 81.25"
  • Overall Length: 92"
  • Spring Center: Pre-drilled at 70" center to center
  • Beam: 2" x 2" Square
  • Spindle: 1 3/8" x 1 1/16" flared
  • Spindle Drop Distance: 2"
  • Flange Hole Distance: 2 7/8" center-to-center



Hardware Information:

  • Inner Bearing (sold separately): 68149 (1 3/8" inner dimension)
  • Outer Bearing (sold separately): 44649 (1 1/16" inner dimension)
  • Grease Seal Inner Diameter: 1.72"



Tie Down Engineering/Dexter Marine of Georgia Part Number: 49857
